  #1
Old 11-12-10, 16:24
maple_leaf_eh maple_leaf_eh is offline
Terry Warner

Join Date: Mar 2004
Location: Shouting at clouds
Posts: 3,152
Default

Quote:
Originally Posted by FV1611A View Post
Thats a clever little impro for a bench vice! The only limitation would be sections only 150mm wide / long. Another option could be a small gauge angle profile that can be tack welded underneath as the angles can be purchased a small as 12x12mm or even 10x10mm / 3/8"x3/8".

I will end up doing some simple fabrication drawings as a master to fabricate from so will share these with you once they are done!

Regards

Wayne
If I have to bend sheet metal I do something similar with my bench vise and a big hammer. The limitation I have to accommodate is the depth of the vise's jaws. But for the man who needs more toys, that one would be just the ticket!
__________________
Terry Warner

- 74-????? M151A2
- 70-08876 M38A1
- 53-71233 M100CDN trailer

Beware! The Green Disease walks among us!
Reply With Quote
  #2
Old 13-12-10, 00:00
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

Quote:
Originally Posted by maple_leaf_eh View Post
If I have to bend sheet metal I do something similar with my bench vise and a big hammer. The limitation I have to accommodate is the depth of the vise's jaws. But for the man who needs more toys, that one would be just the ticket!
Terry simple is sometimes best, albeit are you saying that you can do longer than 6" lengths by folding and then sliding along in the vice to then fold, and so on? Clive mentioned marks on the steel, but I guess the aesthetics depend on where the folded part is seen or used.

I believe that 'Frost Automotive' in the UK do a reasonably priced bench/ vice folder on larger scale than the jaw version posted.
__________________
Wayne
1959 Royal Ordnance FV1611A
Reply With Quote
  #3
Old 13-12-10, 12:18
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

Quote:
Originally Posted by maple_leaf_eh View Post
If I have to bend sheet metal I do something similar with my bench vise and a big hammer. The limitation I have to accommodate is the depth of the vise's jaws. But for the man who needs more toys, that one would be just the ticket!
Terry a man can never, ever have enough toys The wife has asked me what I want for Christmas this year and a pair of 6T (12T pair) HD Ratchet Axle Stands and an Engine Stand are reserved on Santas Sleigh Woop Woop!
__________________
Wayne
1959 Royal Ordnance FV1611A
Reply With Quote
  #4
Old 14-12-10, 14:38
fv1620's Avatar
fv1620 fv1620 is offline
Registered User

Join Date: Nov 2005
Location: (Old) South Wales, UK
Posts: 172
Default

Yes the side lockers for my RUC Pig are different from the production Pig. But these shorter & less complex lockers are not RUC specific as such.

All of the original 20 FV1609s were like this for Troop Trials in 1956. It was only in 1958 that 10 of these were obtained by the Ministry of Home Affairs for RUC use. All but one of these survived for conversion to hard tops by Belfast Tool & Gauge. The 10 that continued in Army usage were converted to FV1611/12 & uparmoured when the lockers of their various kinds were removed. Most of these ended up as hard targets.
__________________
Clive Elliott
GW4MBS
(Old) South Wales
UK
Reply With Quote
  #5
Old 14-12-10, 16:56
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

Quote:
Originally Posted by fv1620 View Post
Yes the side lockers for my RUC Pig are different from the production Pig. But these shorter & less complex lockers are not RUC specific as such.

All of the original 20 FV1609s were like this for Troop Trials in 1956. It was only in 1958 that 10 of these were obtained by the Ministry of Home Affairs for RUC use. All but one of these survived for conversion to hard tops by Belfast Tool & Gauge. The 10 that continued in Army usage were converted to FV1611/12 & uparmoured when the lockers of their various kinds were removed. Most of these ended up as hard targets.
I couldn't have put it better myself......No honestly I couldn't
__________________
Wayne
1959 Royal Ordnance FV1611A
Reply With Quote
  #6
Old 13-09-11, 16:51
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

I have now managed to collect some salvaged and NOS panels for some of the lockers to fabricate replacements in due course thanks to Clive, Ashley and Alison.

Makes life a little easier for copying and the like.

Regards
__________________
Wayne
1959 Royal Ordnance FV1611A

Last edited by FV1611A; 22-02-12 at 23:58.
Reply With Quote
  #7
Old 22-02-12, 23:59
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

I also have 2 same pattern NOS inner wheel arch panels that will assist further together with a full length side locker cover / lid.....All Helps!

__________________
Wayne
1959 Royal Ordnance FV1611A
Reply With Quote
  #8
Old 02-03-12, 22:18
FV1611A's Avatar
FV1611A FV1611A is offline
Wayne

Join Date: Nov 2010
Location: Ross-on-Wye, Herefordshire UK
Posts: 69
Default

I have now move my Humber to a more ideal secure location where she can remain safe and workable....

Images of move and other matters attached.......There is a belief that this FV1611aas in a fil or TV series and hence the decals on the doors, which I have now discovered the words?????? CONTROL....In the UK someone suggested Doctor Who, which whilst totally amazing if cannot be collaborated right now!?



















A small selection of Abstract Images......
__________________
Wayne
1959 Royal Ordnance FV1611A
Reply With Quote
