  #1
Old 26-01-10, 08:49
cliff's Avatar
cliff cliff is offline
Moderator

Join Date: Mar 2003
Location: Gympie, Queensland, Australia
Posts: 3,108
Default

Quote:
Originally Posted by derk derin View Post
Out of all the cargo trucks surplus after the war,they still have to modify these poor vehicles into something they are not!
Derk.
Mainly because a lot of non cargo vehicles like HUP's and Radio trucks were sold far cheaper then a ready to use General Service truck and this made it more economical for people to modify them to what they wanted.
__________________
Cheers
Cliff Hutchings
aka MrRoo S.I.R.

"and on the 8th day he made trucks so that man, made on the 7th day, had shelter when woman threw him out for the night"
MrRoo says "TRUCKS ROOLE"
Reply With Quote
  #2
Old 23-02-10, 00:36
Rob Fast Rob Fast is offline
Registered User

Join Date: Feb 2003
Location: Manitoba Canada
Posts: 851
Default Here is what 4 months of fun gets you!!!

She is coming together, the amount of nuts and bolts on a Cab 12 is mind bogling! I like to give a name to my vehicles, maybe not a common Canadian pracitise, but I like it. Hence Nipper for my HUW and still looking for something relevant for this C8. I am placing it in Sicily/Italy . How does Deanna sound? A good old Winnipeg girl! Vera is taken as we all know. What a great hobby! Cheers for now.

Darn those 13 inch rims and adapters!!!!
Attached Images
File Type: jpg IM001439.JPG (68.3 KB, 143 views)
__________________
1942 C8A- HUW " Wireless Nipper"
1943 F-60S LAAT and 1939 Bofors
1942 C8 Wireless
1943 FAT/ 17 pounder
1941 C15 GS 2B1
Reply With Quote
  #3
Old 23-02-10, 07:26
cmperry4's Avatar
cmperry4 cmperry4 is offline
aka C. Mark Perry (CMP)

Join Date: Aug 2003
Location: Winnipeg, Manitoba, Canada
Posts: 406
Default Name choice

Deanna sounds like a good option. Meanwhile, found my snaps of the C8 that was out a Sydney, will post later.

Also, I have bunch of snaps of that C8A tow truck, too, that the museum had out for display at the Reunion the year before last.
__________________
Member: Prairie Command, Ex-Military Land Rover Association 2110, MVPA 29055
’45 Chevrolet C8A CMP HUP “Staff Car ”, ’82 Land Rover Series III, 109" ex-MoD,
’80 Honda CX500D, ’48 Ferguson TE20
Reply With Quote
  #4
Old 23-02-10, 07:27
derk derin's Avatar
derk derin derk derin is offline
Registered User

Join Date: Oct 2005
Location: West st. Paul,Manitoba
Posts: 846
Default lookin' good

Rob,
No wonder I haven't seen you around lately.Do you let Tony go home at night or do you lock him in the garage to keep working on the truck?Will it be driving when the snow dissapears or do you have to work on the engine to get it going?Great job!The truck will get better gas mileage than my Dakota.
Derk.
__________________
1942 Ford universal carrier Mk 1
1943 Ford 60 cwt long CMP ambulance
1943 Ford GPW 1/4 ton stretcher jeep
1943 Bantam T-3 1/4 ton trailer
BSA folding airborne bicycle ser#R5325 (early)
Reply With Quote
  #5
Old 16-03-10, 01:37
Rob Fast Rob Fast is offline
Registered User

Join Date: Feb 2003
Location: Manitoba Canada
Posts: 851
Default Just plugging away Dirk...

having fun for the most part. Here is question for the 800 cwt. guys out there. Was there a difference between Ford and Chev 13 inch wheel adapters? Were the wheel adapters a different piece or were some built into the brake drum? See pic. What am I looking at here? The search is still on! Cheers Rob
Attached Images
File Type: jpg IMG_1373.jpg (76.9 KB, 78 views)
__________________
1942 C8A- HUW " Wireless Nipper"
1943 F-60S LAAT and 1939 Bofors
1942 C8 Wireless
1943 FAT/ 17 pounder
1941 C15 GS 2B1
Reply With Quote
  #6
Old 16-03-10, 02:33
Paul Singleton Paul Singleton is offline
Registered User

Join Date: Feb 2003
Location: Yarker Ontario Canada
Posts: 514
Default Wheel adapters

Hi Rob,

The Ford does not use the wheel adapters. The Ford uses special hubs and drums made for the military wheels. The Chevy uses the wheel adapters on the rear only, with special hubs and drums on the front axle. Hope this helps.

Paul
Reply With Quote
  #7
Old 28-03-10, 01:53
Rob Fast Rob Fast is offline
Registered User

Join Date: Feb 2003
Location: Manitoba Canada
Posts: 851
Default Thanks for that Paul...

this 800cwt is something completly different for me. Does anyone have some details on the back stowage for my wireless box application? How did the spare tire hold into the back left cabinet? Did the back right cabinet which supported the chorehorse have a hinged access and was there a vertical steel channell running thru the cabinet to house the flexable corehorse exhaust muffler outlet? What is the layout on the right side of the box as far as 19 set set up is concerned? Any help would be appreciated. Cheers Rob

Darn those 13 inch rims and adapters!!!
Attached Images
File Type: jpg IM001442.JPG (70.9 KB, 106 views)
__________________
1942 C8A- HUW " Wireless Nipper"
1943 F-60S LAAT and 1939 Bofors
1942 C8 Wireless
1943 FAT/ 17 pounder
1941 C15 GS 2B1

Last edited by Rob Fast; 28-03-10 at 02:01. Reason: editing
Reply With Quote
  #8
Old 28-03-10, 05:18
cletrac (RIP)'s Avatar
cletrac (RIP) cletrac (RIP) is offline
David Pope

Join Date: Jul 2003
Location: Eston, Sask, Canada
Posts: 2,249
Default

Rob, here are some pics from Gregg's Military Vehicle Profiles that should help you. It looks like the exterior shelf for the Chorehorse just hinged up against the back of the box for storage and you removed the gen set from the cabinet to put it on the shelf when required. The colour pic is a resto so might not be 100% accurate.
Attached Images
File Type: jpg pers 2.jpg (88.0 KB, 64 views)
File Type: jpg 08b 8cwt.jpg (120.6 KB, 65 views)
File Type: jpg 1b2.jpg (121.7 KB, 63 views)
File Type: jpg interior.jpg (115.2 KB, 66 views)
File Type: jpg FRH_2001_May_Andy_Hill_working_a_19_Set_in_back_of_a_1941_CM.jpg (75.2 KB, 73 views)
__________________
1940 Cab 11 C8 Wireless with 1A2 box & 11 set
1940 Cab 11 C8 cab and chassis
1940 Cab 11 C15 with 2A1 & Motley mount & Lewis gun
1940 Cab 11 F15A w/ Chev rear ends
1941 Cab 12 F15A
1942-44 Cab 13 F15A x 5
1942 cab 13 F15A with 2B1 box
1943 cab 13 F15A with 2H1 box
1943 Cab 13 C8A HUP
1944 Cab 13 C15A with 2C1 box
1943 Cletrac M2 High Speed Tractor
MkII Bren gun carrier chassis x 2
Reply With Quote
